5SL4202-6
Siemens 5SL4202-6 MCB - 2A, 2 Pole, B Curve, 10 kA
The Siemens 5SL4202-6 is a 2 A, 2-pole SENTRON 5SL4 Miniature Circuit Breaker with B characteristic and 10 kA breaking capacity. The B curve trips at 3 to 5 times rated current, making it suited to resistive loads such as lighting, heating and socket circuits with long cable runs. Designed for DIN-rail mounting in distribution boards and control panels, it protects cables and equipment against overload and short circuit.
Key Features
- B tripping characteristic: trips at 3 to 5 times rated current
- Breaking capacity 10 kA as per IEC 60898-1
- 2-pole, 2 module width (18 mm per module)
- Protection against overload and short circuit
- DIN-rail mounting (35 mm)
- Compact Siemens design with clear ON/OFF indication
Technical Specifications
| Brand | Siemens |
|---|---|
| Product Range | SENTRON 5SL4 Miniature Circuit Breaker |
| Order Code | 5SL4202-6 |
| Rated Current (In) | 2 A |
| Number of Poles | 2 |
| Rated Voltage | 415 V AC |
| Tripping Characteristic | B Characteristic |
| Breaking Capacity | 10 kA as per IEC 60898-1 |
| Standard | IEC 60898-1 |
| Frequency | 50-60 Hz |
| Module Width | 2 MW (1 MW = 18 mm) |
| Mounting | 35 mm DIN rail |
| Standard Pack | Refer Siemens |
Typical Applications
Resistive loads such as lighting, heating and socket circuits with long cable runs; final distribution boards, control panels and machine wiring in residential, commercial and industrial installations.
Genuine Siemens product supplied by Aventra Systems, authorised Siemens channel partner. Need other ratings, poles, curves or bulk quantities? Contact us for a quotation.
